ASUS - ASUS ExpertCenter D7 SFF D700SA Q53SP
SFF - Core i5 10400 / up to 4.3 GHz - RAM 8 GB - SSD 512 GB - NVMe - UHD Graphics 630 - Gigabit Ethernet - 802.11a/b/g/n/ac, Bluetooth 4.2 - Win 10 Pro - monitor: none - black
Product Description
What's Included
| Main Specifications | |
|---|---|
| Product Description | ASUS ExpertCenter D7 SFF D700SA Q53SP - SFF Core i5 10400 2.9 GHz - 8 GB - SSD 512 GB |
| Type | Personal computer - SFF |
| Processor | Intel Core i5 (10th Gen) 10400 / 2.9 GHz (, up to 4.3 GHz, (6-core) |
| Cache Memory | 12 MB |
| Cache Per Processor | 12 MB |
| RAM | 8 GB (installed) / 128 GB (max) - DDR4 SDRAM |
| Storage Controller | SATA (SATA 6Gb/s) |
| Hard Drive | SSD 512 GB - PCI Express 3.0 - M.2 - NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Graphics Controller | Intel UHD Graphics 630 |
| Audio Output | 7.1 channel surround |
| Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Bluetooth 4.2 |
| OS Provided | Windows 10 Pro |
| Software Included | Microsoft 365 (30 days trial), McAfee LiveSafe (30 days trial) |
| Color | Black |
| Dimensions (WxDxH) | 9.5 cm x 29.28 cm x 34 cm |
| Weight | 5 kg |
| General | |
| Type | Personal computer |
| Product Form Factor | SFF |
| Embedded Security | Trusted Platform Module (TPM 2.0) and firmware (TPM) |
| Color | Black |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x internal 2.5" |
| Slots | 1 (total) / 1 (free) x PCIe 3.0 x16 ¦ 3 (total) / 1 (free) x M.2 Card ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 ¦ 1 (total) / 1 (free) x PCI |
| Interfaces | 1 x headphones (1 in front) ¦ 1 x headphones/microphone (1 in front) ¦ 6 x USB 3.2 Gen 1 (6 in front) ¦ 4 x USB 3.2 Gen 1 ¦ 1 x HDMI ¦ 1 x DisplayPort ¦ 1 x VGA ¦ 1 x audio line-out ¦ 1 x audio line-in ¦ 1 x PS/2 keyboard ¦ 1 x PS/2 mouse ¦ 1 x USB-C 3.2 Gen 1 (1 in front) ¦ 1 x microphone ¦ 1 x LAN (Gigabit Ethernet) |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Compliant Standards | UL, BSMI, CB, CCC, FCC, MIL-STD 810G |
| RAM | |
| Installed Size | 8 GB (installed) / 128 GB (max) |
| Technology | DDR4 SDRAM |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) |
| Features | Unbuffered |
| Networking | |
| Ethernet Controller | Intel I219-V |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2 |
| Power | |
| Device Type | Power supply |
| Power Provided | 300 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Storage Controller | |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 3 |
| Cache Memory | |
| Installed Size | 12 MB |
| Cache Per Processor | 12 MB |
| Optical Storage | |
| Type | No optical drive |
| Operating System / Software | |
| OS Provided | Windows 10 Pro |
| Software | Microsoft 365 (30 days trial), McAfee LiveSafe (30 days trial) |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 630 |
| Video Interfaces | VGA, HDMI, DisplayPort |
| Audio Output | |
| Sound Output Mode | 7.1 channel surround |
| Compliant Standards | High Definition Audio |
| Hard Drive | |
| Type | SSD - M.2 |
| Capacity | 1 x 512 GB |
| Interface Type | PCI Express 3.0 |
| Features | NVM Express (NVMe) |
| Dimensions & Weight | |
| Width | 9.5 cm |
| Depth | 29.28 cm |
| Height | 34 cm |
| Weight | 5 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 22.2 cm |
| Shipping Depth | 41 cm |
| Shipping Height | 49.2 cm |
| Processor / Chipset | |
| CPU | Intel Core i5 (10th Gen) 10400 |
| Clock Speed | 2.9 GHz |
| Max Turbo Speed | 4.3 GHz |
| Number of Cores | 6-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Chipset Type | Intel B460 |
